Building a Dual-Mode Web Server with ESP32: AP and Station Simultaneously

Published in

Engineering IoT

3 min readOct 5, 2024

Introduction

In today’s IoT landscape, flexibility is key. What if you could have your ESP32 connect to your home network while simultaneously creating its own access point? In this tutorial, we’ll build a sophisticated web server that does exactly that, complete with multiple pages, animations, and authentication.

What We’ll Create

Our ESP32 will:

Connect to your existing WiFi network (Station mode)
Create its own access point
Serve a multi-page website with:

A welcoming homepage with network information
A live-updating clock
A secure page with detailed network stats
A goodbye page with animations

The Hardware

For this project, you’ll need:

An ESP32 development board
A micro USB cable
A computer with Arduino IDE/VsCode installed

The Code Structure

Our code is organized into several key components:

Network Configuration

// Station Mode Credentials
const char* sta_ssid = "YourWiFiName";
const char* sta_password = "YourWiFiPassword";

// AP Mode Credentials
const char* ap_ssid = "ESP32_AP";
const char* ap_password = "12345678";

HTML Template System We use a function to generate consistent HTML across all pages:

String getPage(String content) {
  String html = "<!DOCTYPE html><html><head>";
  // ... styling and navigation ...
  html += content;
  html += "</div></body></html>";
  return html;
}

Page Handlers Each page has its own handler function:

void handleHome() {
  String content = "<h1>Welcome to ESP32 Web Server</h1>";
  // ... page content ...
  server.send(200, "text/html", getPage(content));
}

Key Features

1. Dual-Mode Operation

void setup() {
  WiFi.mode(WIFI_AP_STA);  // Enable both AP and Station modes
  WiFi.softAP(ap_ssid, ap_password);  // Start the access point
  WiFi.begin(sta_ssid, sta_password); // Connect to existing network
}

2. Authentication

bool is_authenticated() {
  if (!server.authenticate("admin", "admin")) {
    server.requestAuthentication();
    return false;
  }
  return true;
}

3. Live Updates

We use JavaScript for real-time clock updates:

function updateClock() {
  const now = new Date();
  document.getElementById('clock').textContent = now.toLocaleTimeString();
}
setInterval(updateClock, 1000);

Implementation Details

Setting Up the Web Server

WebServer server(80);

void setup() {
  // ... network setup ...
  server.on("/", handleHome);
  server.on("/timer", handleTimer);
  server.on("/info", handleInfo);
  server.on("/goodbye", handleGoodbye);
  server.begin();
}

Main Loop

void loop() {
  server.handleClient();
}

Accessing Your Web Server

Connect your device to either:

Your home network (using the station mode IP)
The ESP32’s access point (default IP: 192.168.4.1)

Open a web browser and enter the appropriate IP address

Navigate through the pages using the top navigation bar

Security Considerations

The info page is protected with basic HTTP authentication
Consider changing default credentials in production
AP mode password should be at least 8 characters

Potential Enhancements

Add HTTPS support for secure connections
Implement a captive portal for the AP mode
Add WebSocket support for real-time sensor data
Create a configuration page to change network settings

Troubleshooting

Common issues and solutions:

Can’t connect to WiFi: Double-check credentials
Web server not responding: Verify IP addresses
Authentication issues: Clear browser cache

Conclusion

This project demonstrates the versatility of the ESP32, showing how it can operate in both AP and station modes simultaneously while serving a feature-rich web interface. The possibilities for expanding this foundation are endless — from home automation to sensor monitoring and beyond.
